2024 BMB Chamber belt system with shrink tank

2024 BMB Chamber belt system with shrink tank

Contact us for price

Location:Hamburg, Germany

Description

We are offering for sale a Chamber belt system with shrink tank. LikeNEW! Barey used


CHAMBER BELT VACUUM MACHINE

Model: Conveyor Pro 1065

Packable Products

  • Meat
  • Sausages
  • Cheese
  • Fish
  • Fruits
  • Vegetables
  • Ready meals
  • Mechanical components
  • Electronic components

Technical Data

  • Structure: Stainless Steel AISI 304
  • Control Panel: 7" PLC Touchscreen
  • Dimensions (L×W×H): 2741×1237×1645 mm
  • Weight: 900 kg
  • Inner Vacuum Chamber Size: 1110×840 mm
  • Usable Lid Height: 250 mm (Optional: 150-200-320 mm)
  • Sealing Bars: 1 or 2 × 1000 mm
  • Distance Between Sealing Bars: 670 mm
  • Sealing Type: Monoseal or bi-active, double seal or wide sealing
  • Conveyor Belt Speed: Variable, up to 40 m/min
  • Vacuum Pump: 1 or 2 × 300 m³/h (7.5-15 KW) + Booster 500 or 1000 m³/h (5.5 KW)
  • Final Vacuum Degree: 1 mbar absolute
  • Power Supply: 400V - 3PH + N + PE - 50Hz - 3KW (without pump)
  • Pneumatic Supply: 6/8 bar - dry and microfiltered air
  • Air Consumption: 60 Nl/cycle
  • Speed: 2-3 cycles/min


SHRINKING AND DRYING SYSTEM

Model: Shrink Tunnel RT 65

Technical Data

  • Structure: Stainless Steel AISI 304
  • Control Panel: 7" PLC Touchscreen
  • Dimensions (L×W×H): 1500×1300×1755 mm
  • Weight: 450 kg
  • Usable Area (L×W): 1210×660 mm
  • Usable Chamber Height: 300 mm
  • Water Tank Capacity: 200 l
  • Hot Water Preparation: Electric resistances or steam injection
  • Conveyor Belt Speed: 2-6 m/min
  • Power Consumption: 3KW (steam), 30/60KW (electric)
  • Power Supply: 400V - 3 Phase + N + PE
  • Air Consumption: 50 Nl/min
  • Speed: Continuous cycle 0.6 m/sec





Find more here - https://www.ucymachines.com/


Contact us at - sales@ucymachines.com

Specifications

ManufacturerBMB
ModelChamber belt system with shrink tank
Year2024
ConditionUsed
Stock Number755907
