2014 Yarn Production Machinery
![Used 2014 Rieter R60](https://i.machineryhost.com/47fd3c87f42f55d4b233417d49c34783/86064a198036c2c078270c7835c077c7/large-used-2014-rieter-r60.jpg)
2014 Yarn Production Machinery
Contact us for price
Location:Turkey
Available quantity:10
Description
YARN PRODUCTION MACHINERY:
2X 2014 RIETER A11 UNIFLOC MACHINE
2X 2014 RIETER A48 HEAVY METAL SEPARATOR
2X 2014 RIETER B12 UNICLEAN
2X 2014 RIETER B76 UNIMIX
2X 2014 RIETER A79 UNISTOR
2X 2014 RIETER A21 CONDENSER
2X 2014 JOSSI MAGIC EYE
2X 2014 JOSSI TVS XSPECT
1X 2014 RIETER B25 WASTE OPENER
1X 2014 RIETER UNICONTROL
2X 2015 ARGEMA SMT 64500
14X 2014 RIETER C70 CARD MACHINE
4X 2016 RIETER C70 CARD MACHINE
6X 2014 RIETER SB-D 45
6X 2014 RIETER RSB-D 45
1X 2014 RIETER SPIDERWEB
10 X 2014 RIETER R60 Open End Spinning
• Make : Rieter
• Model : R60
• Year : 2014
• No of Rotors : 600
• Yarn Clearer Make : Rieter Q10
• Piecer Carriage : 4
• Opening Roller Type : B174 N-64
• Rotor Diameter in mm : 33
• Length Measuring : Available
• Type of Spinbox : R60
• Type of Drum : SRZ
• Conicity : Cylindrical
• Rotor Drive Type : Aero - bearing
• Rotor Type : 33–XT-BD-AE1
The R 60 offers up to 540 spinning positions per machine. This
makes it the longest rotor spinning machine in the world. With
this large number of rotor positions, high delivery speeds of up
to 260 m/min are possible. Shorter machines can even achieve
speeds of up to 350 m/min. Rotor speeds up to 170 000 rpm
complete the high productivity potential.
TECHNOLOGICAL ADV ANCE WITH THE S 60 SPINNING UNIT
The new S 60 is based on the outstanding properties of the SC-R
spinning box, supplemented by valuable innovations. All the main
advantages, such as BYpass, fixed fiber support, fixed fiber tuft
support and SPEEDpass are also to be found in the new S 60 unit.
With the R 60, rotor speeds up to 5 % higher can be achieved
without jeopardizing yarn quality. The new spinning geometry of
the R 60 lowers spinning tension. The result is fewer yarn breaks
during spinning and better working capacity of the yarn produced
for the next process.
The “cool nozzle” design prevents fiber accumulations and improves
heat dissipation in the technologically important area of
the exit nozzle. Especially when producing synthetic fibers, the
cooling effect of “cool nozzle” technology has a very positive impact
on productivity and quality.
USER-FRIENDLY AUTOMATIO N CONCEPT
The simple, modular design of the robots on the R 60 permits
fast cycles for package changing (doffing), piecing and rotor
cleaning in just 20 seconds.
The R 60 can be equipped with up to 4 of these fast robots
• providing the highest machine efficiencies
• producing strong and invisible piecings with AEROpiecing®
• cleaning the rotor grooves perfectly with VARIOclean at each
piecing and doffing cycle.
Only Rieter provides individual robot service stations at the
foot end and headstock of machines with more than 2 robots.
They enable the other robots to easily take over service for the
whole machine if one of the robots is undergoing maintenance.
The user-friendliness of Rieter automation systems for rotor
spinning machines is mill-proven and well established. Your
maintenance staff will enjoy working with the R 60 robots.
Settings are made very comprehensively by means of the
unique eXpert Piecing System XPS. Only 6 parameters have
to be set on the robot’s graphic display. Ergonomics and short
maintenance times are guaranteed.
PRODUCTIVITY
• Machine length of up to 540 positions with rotor speeds
up to 170 000 rpm
• Higher machine efficiency with lower spinning tension,
resulting in fewer yarn breaks
• Higher speeds with synthetic fibers thanks to “cool nozzle”
technology
• Very fast robots for high machine efficiency even at high rates
of ends down and clearer cuts
• Minimal operator cost, using large can and package sizes of
up to 6 kg and 350 mm diameter
FLEXIBILITY
• Independent machine sides to produce two different lots
simultaneously (option)
• Easy lot change with all spinning elements and the new
TWISTunit
• VARIOspin (option) powered by Amsler Tex for the production
of high-quality slub yarns with maximum productivity
• 1, 2, 3 or 4 robots with service stations for easy robot service
with little influence on machine efficiency
• Double capacity tube loader with independent sides (option)
QUALITY
• Superior yarn evenness and quality with the new S 60
spinning unit
• ”Cool nozzle“ technology prevents fiber damage, especially
with synthetic fibers
• Superior running performance achieved with adjustable
trash extraction using BYpass
• Highest yarn quality due to the fixed fiber tuft support
and SPEEDpass (optional)
• Broad spinning component portfolio for optimal yarn
construction
• The Rieter rotor yarn is branded under the name Com4®rotor
ECONOMY
• Up to 5 % less energy consumption thanks to newly designed
rotor geometry and suction system
• Low loss of good fibers thanks to the BYpass system of the
S 60 spinning unit
• Good space utilization due to narrow machine design
and 540 spinning positions
• Easy access for fast operation and maintenance
ADITIONAL MACHINES & EQUIPMENT
1X 2014 KAVURLAR AST BOX FIBER BALING PRESS (60 TON)
4X 2014 TEMSANAIR CONDITIONING UNIT (9000 ROTOR)
2X 2014 EKOMAK EKO132 QD VST 32KW SCREW AIR COMPRESSOR (WITH INVERTER)
1X 2014 EKOMAK CAD 500 COMPRESSED AIR DRYER
2X 2014 EKOMAK G 430 COMPRESSED AIR FILTER
1X 2014 EKOMAK 5000LT COMPRESSED AIR TANK
1X 2014 PREMIER ART2-LSMCT FULLY AUTOMATIC HIGH VOLUME COTTON TESTING EQUIPMENT
1X 2014 PREMIER AQUARA2 PROCESS AND FIBRE INFORMATION SYSTEMS
1X 201 PREMIER TENSOMAX SINGLE YARN TESTER
1X 2013 PREMIER İQ2 LX EVENNESS TESTER
1X 2014 STULZ CCU121A PRECISION CONTROLLED AIR CONDITIONING DEVICE (FOR
LABORATORY)
1X 2014 ZANCANER PACKAGING MACHINE
1X 2014 XQRELLA XSC-R 2900*1400* YARN FIXING MACHINE
1X 2007KIRAZ PALLET STRETCH PACKAGING MACHINE
8000X BIANCO BI.470*1070YK SPINNING CANS WITH SPRING SYSTEMS
280X BIANCO BI.1000*1200YKT SPINNING CANS WITH SPRING SYSTEMS AND CASTORS
1X 2015 BRACKER GRINDING MACHINE
Find more here - https://www.ucymachines.com/
Contact us at - sales@ucymachines.com
Specifications
Manufacturer | Yarn Production Machinery |
Year | 2014 |
Condition | Used |
Stock Number | 1337 |
