2019 MTU VPOWER GENERATOR P1600

VPOWER Generator Set Details

• Genset Model: P1600
• Power Output: 1600 kW

AC Generator Data

• Phase: 3 Phase, 4 Wire
• Specification: Class H / 125K / 40°C
• Voltage: 400 V
• Amperes: 3002 A
• Frequency: 50 Hz
• Rating: Continuous
• Power Factor (PF): 0.8
• Poles: 4

Engine Data

• Continuous Duty: 1635 kWm @ 1500 RPM
• Prime Duty: 1798 kWm @ 1500 RPM
• Standby Duty: 1965 kWm @ 1500 RPM
• Fuel: Diesel

Engine Details:

• Manufacturer: MTU
• Model: 16V 4000 G23
• Year of Manufacture: 2017
• Power: 1788 kW
• Speed: 1500 rpm
• Mass: 3740 kg

Generator Details

• Manufacturer: Stamford
• Model/Frame: P.I734F1
• Frequency: 50/60 Hertz
• RPM: 1500 / 1800
• Voltage: 400 / 440 V
• Base Rating:
• kVA: 2080.0 (BR) / 2500.0 (BR)
• kW: 1664.0 / 2000.0
• Ampere Rating: 3002.3 / 3280.4
• Excitation Voltage: 63.0 V
• Excitation Current: 3.6 A
• Power Factor (PF): 0.80
• Insulation Class: Class H
• Ambient Temperature: 40°C
• Temperature Rise: 125 K
• Thermal Classification: 180(H)
• Enclosure: IP23
• Stator Connection: Star
• Stator Winding: 312
• Mounting Type: IMB15
• Cooling Method: IC01
• Weight: 3840 kg
• AVR: MX321
